5M COB LED Strip Kit - with Dotless RGB LED COB Strip, 24vdc, Colour Changeable) (630 LEDs/M) 5M Reel

Product Code: 630-10MM- RGB-9W-KIT

£134.00 inc VAT (£111.67 ex VAT)

Stock Level: In-Stock

Select Colour Controller
Select Power Supply Unit (Transformer/Driver)
Quantity :

Wi-Fi Lightbox (Alexa/Google Assistant) adds £16 to price



Product Description

This Strip incorporates 630 LEDs per Metre, which produces a dot-free or dotless appearance without any diffusers. Ideal for applications where there is no space for a diffuser or profile. It can also be used in any of our profiles where you want a Neon look.

A 5M reel has 3,150 LEDs

Full colour changing capability with our Lightbox - Bluetooth Controller, or WiFi Lightbox (Wi-Fi).

Included with the Kit is a 60w LED Driver or wiring to a lighting circuit / light switch. Both controllers remember their last setting so will automatically resume their last settng when switched on from the light switch without you needing to use the App.

  • RGB - 16.7 Milliion colours including whites, warm white, and pastels
  • Cutting points every 10cm
  • 24vdc - no voltage drop issues
  • 50cm wire soldered on both ends*

The pre-soldered wires on both ends of the LED Strip allows the Stirp to be cut once without having to make new connections, the off-cut will already be wired ready to use.

Product Specification

Working Voltage Range24vdc
LED TypeFC COB
LED BrandSanan
RGB ValuesR:615-630nm
G:520-535nm
B:450-460nm
Brightness per Metre~550Lm
Current per Meter375mA
Power Draw per Meter9 Watts
Light Dispersion180 °
Width of LED Strip10mm
Depth of LED Strip2.2mm
Lengths available5M
Lifetime>25,000 hours
LEDs per Meter630
Cutting Points100mm
Wire pre-fitted0.5M on both ends
IP RatingIP20 (Non Waterproof)
Warranty2 Years
CertificationsCE, RoHS, LM-80, UL, EC, UKCA, Eye Safe IEC/EN 62471
